2024 4K HDMI LAN 60FPS Optical 28X Zoom Auto focus Focal Industry Microscope Camera Stand Light Set with Measurement (M114)

2024 4K HDMI LAN 60FPS Optical 28X Zoom Auto focus Focal Industry Microscope Camera Stand Light Set with Measurement (M114)

$745.00



  • Description
  • Reviews
  • Shipping & Returns





















































































4K Video Electric zoom 1X-28X Optical Zoom (M114)
Autofocus HDMI LAN Autofocus Industrial Microscope Camera Optics Lens Large Field Of View
with Measuring Function For PCB SMD SMT Repair, Cultural relics collection





Feature:



  • 4K FULL HD high speed camera with 1X - 28X optics zoom lens
  • Electric zoom, The magnification can be adjusted through a mouse or other I/O device
  • UI design menu, easy to control by mouse
  • Autofocus, when observation Objects of different heights, you do not need adjust the lens's Working distance
  • When you adjust the Camera's Magnification, you do not need adjust the lens's Working distance















Specification:



  • 4K HDMI / LAN POE video output

  • High performance and fast response video

  • H.264 codec

  • 4K/1080P switch adaptively, 4K Preview frame rate 30fps, 1080P Preview frame rate 60fps

  • SONY imx415 Sensor, senzor size:1/2.8"

  • Pixel(μm) : 1.45x1.45

  • Resolution: 4K Ultra HD (8mp 3840x2160)

  • Preview frame rate: 4K@30fps / 1080P@60fps

  • Exposure : 1/50s(1/60s)~1/10000s

  • Real time measurement

  • Support U disk storage

  • Method of Operation : Mouse

  • Power DC : DC12V

  • Video Output method : HDMI, LAN POE

  • White Balance : Auto / Manual / One-push control

  • Exposure : Auto / Manual

  • Scanning method : Line by line scanning

  • Operating Temperature : 0℃~50℃

  • Magnification / Zoom : Support

  • Menu language : Chinese/English/Japanese

  • The actual magnification is below for reference:

    M114:
    If 27-inch monitor and working distance is 10cm:
    Optical 1X - actual magnification 3.8X
    Optical 14X - actual magnification 22.7X
    Optical 28X - actual magnification 50X
    Optical 28X + 3X digital - actual magnification 145X

    M114S:
    If 27-inch monitor and working distance is 6-7cm:
    Optical 1X - actual magnification 5.5X
    Optical 14X - actual magnification 35X
    Optical 28X - actual magnification 70X
    Optical 28X + 3X digital - actual magnification 210X














LPM114 SET Package including:



  • 1 x Microscope Camera (LPM114)
  • 1 x Power supply(AU/EU)
  • 1 x HDMI Cable
  • 1 x LAN Cable
  • 1 x USB Mouse
  • 1 x Camera Big Stand
  • 1 x Universal microscope bracket
  • 1 x 40LED Rign Light
  • 1 x Heat Insulation Silicone Pad



Instructions:



9

  • 1. Item will be shipped within 3 days after payment received
  • 2. Tax: we are not responsible for the import tax and customs charges at destination country
  • 3. Usually we ship the item by standard shipping if the item weight is less than 2KG, but if the item has high value and weight is over 2KG, we will ship by DHL / UPS / FedEx express shipping, usually the shipping time is about 5-10 days to your country(depends on the customs clearance schedule).
  • 4. Important! International shipment not under our control, sometimes delayed please contact us let me know. We will check for you. Over 30 days have not arrive after we checked will be replacement or give other solution. Thank you~

11
  • 1. The warranty period is one year
  • 2. If you are unhappy with your purchase, please contact us within 30 days of receipt and let us know why.
  • 3. We would like to assure the all products can be arrived on time and in good condtion, but some quality problem caused by such as manufacture, material or bad quality under normal use. Defective/ Wrong Items - within the warranty period---please contact with us directly, a picture or video will be better understand the probem, so that we can provide the best suitable solution.
